Bandwidth(-3dB）

100MHz

Rise time

≤3.5ns

Accuracy

±2%

Range selection

(Attenuation rate)

10X/100X

50X/500X

100X/1000X

100X/1000X

Maximum differential voltage(DC + Peak AC)

10X

±70V

50X

±150V

100X

±350V

100X

±700V

100X

±700V

500X

±1500V

1000X

±3500V

1000X

±7000V

Common mode voltage (Vp)

(DC + Peak AC)

±700V

±1500V

±3500V

±7000V

Maximum differential mode VS frequency curve

Reference Figure 1

Figure 2

Figure 3

     Figure 4

Maximum input

voltage-to-earth (Vrms)

  450V CATII

600V CATI*

600V CATIII

1000V CATII

600V CATIII

1000V CATII

   1000V CATIII

2300V CATI*

Input impedance

Single-ended to ground

2.5MΩ

5MΩ

5MΩ

20MΩ

Between inputs

5MΩ

10MΩ

10MΩ

40MΩ

Input capacitance

Single-ended to ground

＜4pF

＜4pF

＜4pF

＜5pF

Between inputs

＜2pF

＜2pF

＜2pF

＜2.5pF

CMRR

DC

＞80dB

＞80dB

＞80dB

＞80dB

100kHz

＞60dB

＞60dB

＞60dB

＞60dB

1MHz

＞50dB

＞50dB

＞50dB

＞50dB

Noise(Vrms)

10X

＜25mV

50X

＜50mV

100X

＜100mV

100X

＜220mV

100X

＜120mV

500X

＜300mV

1000X

＜600mV

1000X

＜1.2V

Differential overvoltage detection level

10X

≥70V

50X

≥150V

100X

≥350V

100X

≥700V

100X

≥700V

500X

≥1500V

1000X

≥3500V

1000X

≥7000V

Propagation  time

Probe

10X

8.7ns

50X

8.5ns

100X

8.2ns

100X

8.9ns

100X

8.1ns

500X

7.5ns

1000X

7.4ns

1000X

6.6ns

BNC Line(1m)

About 5ns

Bandwidth limit filters (5MHz)

≥-3dB@5MHz

Overload indicator (red light）

Yes

Overload alarm

Yes(Can shut up manually)

Automatic save

Yes

Offset setting function

Yes（ Set in test mode）

Terminate load

≥100kΩ

Power supply

USB 5V/1A adapter

Safety standard

IEC/EN 61010-031:2015 + AMD1:2018

EMC standard

EN61326-1:2013  EN61000-3-2:2006+A1:2009+A2:2009  EN61000-3-3:2013
